- Intel® Core™ i5-6500T Processor (2.5 GHz, up to 3.1 GHz with Intel Turbo Boost, 6 MB cache, 4 cores)
- Windows 7 Professional 64 (available through downgrade rights from Windows 10 Pro)
- Intel® HD Graphics 530
- 8 GB DDR4-2133 SDRAM (1 x 8 GB)
- 256 GB SATA SSD
Features
Performance for the enterprise
Power through your day with the performance you need in a PC driven by the latest 6th Gen Intel® Core™ processors[2] plus Intel® HD Graphics.
Security designed to deter downtime
Get maximum uptime with HP BIOSphere[3] with SureStart, which helps stop attacks at the BIOS, HP Client Security Suite’s[4] data protection, and multi-factor authentication.
Versatility to build a better workspace
Deploy the Mini almost anywhere with the VESA-enabled flexible mounting options including optional accessories, and VESA ready displays. Customize your solution with a full range of expandability, security, and mounting accessories.[5]
Ready to run
This Mini endured 120,000 hours of performance trials during the HP Total Test Process and is designed to undergo MIL-STD 810G testing.[6] Help keep your PC cool in challenging work environments with HP temperature controls.
Supported Operating Systems |
Operating system |
Windows 7 Professional 64 (available through downgrade rights from Windows 10 Pro) |
Operating system note |
This
system is preinstalled with Windows 7 Professional software and also
comes with a license and media for Windows 10 Pro software. You may only
use one version of the Windows software at a time. Switching between
versions will require you to uninstall one version and install the other
version. You must back up all data (files, photos, etc.) before
uninstalling and installing operating systems to avoid loss of your
data. |
Processor |
Chipset |
Intel® Q170 |
Processor speed |
2.5 GHz |
Processor family |
Intel® Core™ i5 processor |
Processor |
Intel® Core™ i5-6500T with Intel HD Graphics 530 (2.5 GHz, up to 3.1 GHz with Intel Turbo Boost, 6 MB cache, 4 cores) |
Memory |
Memory, standard |
8 GB DDR4-2133 SDRAM (1 x 8 GB) |
Memory slots |
2 SODIMM |
Drives |
Hard drive description |
256 GB SATA SSD |
Internal drive bays |
One 2.5" |
Storage type |
SSD |
Graphic Subsystem |
Graphics |
Intel® HD Graphics 530 |
Graphics |
Integrated |
Multimedia |
Audio |
DTS
Studio Soundâ„¢ audio management technology, HD audio with Realtek ALC221
codec (all ports are stereo), microphone and headphone front ports (3.5
mm), audio line-out rear port (3.5 mm), multi-streaming capable,
internal speaker |
Input devices |
Keyboard |
HP USB Business Slim Keyboard |
Pointing device |
HP USB Mouse |
Connectivity and Communications |
Network interface |
Intel® i219M GbE |
Ports |
2 USB 3.0 (1 charging) 1 USB Type-Câ„¢ 1 headphone/microphone 1 headphone connector |
Expansion slots |
2 M.2 |
Expansion slots note |
1 M.2 PCIe for WLAN. 1 M.2 PCIe for storage |
I/O Port location |
Front |
Ports |
4 USB 3.0 1 RJ-45 1 VGA 1 serial (optional) 1 HDMI (optional) 2 DisplayPort (1 optional) |
I/O Port location |
Back |
Ports note |
If serial or HDMI is selected, then only 1 Display Port remains available. |
Battery and Power |
Power |
65 W 89% efficient (external) |
Weights |
Weight |
1.3 kg |
System Components |
Form factor |
Mini |
Security Management |
Security management |
Security Loop Hood sensor HP BIOSphere with Sure Start HP Active Health Infineon TPM SLB9670 1.2/2.0 |
Security management footnote number |
[10] |
|
Software footnote number |
[8,9] |
Dimensions |
Minimum dimensions (W x D x H) |
175 x 177 x 34 mm |
Warranty |
Warranty |
3-year
(3-3-3) limited warranty and service offering includes 3 years of
parts, labor and on-site repair. Terms and conditions vary by country.
Certain restrictions and exclusions apply. |
